Mini Rocker Switch Red Button Black Housing 2 Pin ON-OFF - KCD1-101-R
Mini Rocker Switch Red Button Black Housing 2 Pin ON-OFF - KCD1-101-R - Image 2
Mini Rocker Switch Red Button Black Housing 2 Pin ON-OFF - KCD1-101-R - Image 3
Mini Rocker Switch Red Button Black Housing 2 Pin ON-OFF - KCD1-101-R - Image 4

Mini Rocker Switch Red Button Black Housing 2 Pin ON-OFF – KCD1-101-R

Original price was: ₹13.00.Current price is: ₹7.00.

  • The KCD1-101 miniature rocker switch is a SPST switch with ON-OFF operation, designed for various electrical applications. It has a durable nylon 66 housing and button, with brass terminals that are silver plated. The switch is rated at 10A 125VAC/6A 250VAC and has a contact resistance of 35mOhm max. It can operate in temperatures ranging from -25C to +85C and has a mechanical life of >= 100,000 cycles. The switch is available in black and red or white and beige button colors, and has CE, CQC, and SGS certifications. This switch is ideal for OEM or ODM applications.
    Features
    Category: Miniature Rocker Switch
    Housing: Nylon 66
    Button: Nylon 66
    Terminal: Brass with silver plating
    Button color: Black and Red, white and beige color
    Housing color: Standard black and red, white and beige color
    Rating: 10A 125VAC/6A 250VAC
    Contact Configuration: SPST
    Switch Operation: ON-OFF
    Contact Resistance: 35mOhm max
    Operating Temperature: -25C~+85C
    Insulation Resistance: 100mOhm min (500VDC)
    Dielectric Strength: 1500VAC 1 minute
    Mechanical Life: >= 100,000 Cycles
