ESP8266 NodeMCU CH340 Wi-Fi Microcontroller Board
ESP8266 NodeMCU CH340 Wi-Fi Microcontroller Board - Image 2
ESP8266 NodeMCU CH340 Wi-Fi Microcontroller Board - Image 3
ESP8266 NodeMCU CH340 Wi-Fi Microcontroller Board - Image 4

ESP8266 NodeMCU CH340 Wi-Fi Microcontroller Board

Original price was: ₹399.00.Current price is: ₹299.00.

  1. Power input: 4.5V ~ 9V (10VMAX), USB-powered
  2. Transfer rate: 110-460800bps
  3. Support UART / GPIO data communication interface
  4. Support Smart Link Smart Networking
  5. Working temperature: -40°C ~ + 125°C
  6. Drive Type: Dual high-power H-bridge
  7. Don’t need to download resetting
  8. A great set of tools to develop ESP8266
  9. Flash size: 4MByte
  10. Lowest cost WI-FI

This Microcontroller board can do work as same as arduino uno, but has wifi system inbuilt. Projects like home automation, Automated irrigation all this things are for This Board. NodeMCU is an IoT Module based on the ESP8266 wifi Module Board. NodeMCU uses Lua Scripting language and is an open-source Internet of Things (IoT) platform. This module has CH340g USB to TTL IC. It is based on ESP8266, integrates GPIO, PWM, IIC, 1-Wire, and ADC all in one board. Power your development in the fastest way in combination with NodeMCU Firmware. USB-TTL included plug&play. 10 GPIO, every GPIO can be PWM, I2C, 1-wire.

Features :

  1. Uses CH340G instead of CP2102.
  2. Wireless 802.11 b/g/n standard
  3. WiFi at 2.4GHz, support WPA / WPA2 security mode
  4. Support STA/AP/STA + AP three operating modes
  5. Built-in TCP/IP protocol stack to support multiple TCP Client connections (5 MAX)
  6. Support UART / GPIO data communication interface
  7. Remote firmware upgrade (OTA)
  8. Support Smart Link Smart Networking
  9. ESP8266 has IO Pin
  10. Don’t need to download resetting
  11. A great set of tools to develop ESP8266
  12. Lowest cost WI-FI
  13. FOR Arduino like hardware IO
  14. Greatly speed up your IOT application developing process
  15. Open-source, Interactive, Programmable, Low cost, Simple, Smart, WI-FI enabled
  16. WI-FI MCU ESP8266 integrated and easy to prototyping development kit.
  17. We provide the best platform for IoT application development at the lowest cost.
